Cisco CBS220-24P-4X Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White

Part #:
CBS220-24P-4X
Availability:
In Stock
Price:
Excl VAT: AED 557.00 Incl VAT: AED 584.85
The Cisco Business 220 Series are affordable smart switches with ease of use, security, and reliability for business-class networks. With intuitive dashboard, Power over Ethernet (PoE) options, and customizable features, these switches deliver a solid business network within your budget parameters. When you need a business-class network and cost is top priority, Cisco Business 220 Series provides an excellent solution. With Cisco Business 220 Series switches, you can not only build an efficient and reliable network to connect the workforce, you can also create advanced solutions to deliver data, voice, and video services on a converged infrastructure. Get the best value for your money by improving the productivity of employees. Cisco Business 220 Series provides capabilities that help you create business-class networks. These features deliver a solution to simplify the operation, increase uptime, and get your business better connected to employees, customers, and suppliers.
Ports & interfaces
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity8
Technical details
Product colourGrey
Mean time between failures (MTBF)2066844 h
Rack mountingNo
Management features
Switch typeUnmanaged
Quality of Service (QoS) supportYes
Switch layerL2
Network
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Networking standardsIEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Full duplexYes
Head-of-line (HOL) blockingYes
Flow control supportYes
Ethernet LAN data rates10,100,1000 Mbit/s
Auto MDI/MDI-XYes
10G supportNo
Half duplexYes
Data transmission
Jumbo frames9216
MAC address table8192 entries
Switching capacity16 Gbit/s
Number of queues4
Jumbo frames supportYes
Forwarding rate11.9 Mpps
Security
Queue scheduling algorithmsWeighted Round Robin (WRR)
Certificates
CertificationUL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B
Design
Product colourGrey
LED indicatorsYes
CertificationUL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B
Rack mountingNo
Performance
Mean time between failures (MTBF)2066844 h
Harmonized System (HS) code85176990
Indication
LED indicatorsYes
Power
Power supply includedYes
Redundant power supply (RPS) supportNo
Number of power supply units1
DC input voltage12 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Operational conditions
Storage temperature (T-T)-20 - 70 °C
Storage relative humidity (H-H)5 - 90%
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%
Heat dissipation14.09 BTU/h
Weight & dimensions
Width160 mm
Depth104 mm
Height30 mm
Weight430 g
Packaging data
Quick start guideYes
Other features
Ethernet LAN data rates10,100,1000 Mbit/s
Packaging content
Quick start guideYes
More Information
SKUCBS220-24P-4X
